Pentair BioShield Quartz Sleeve 523040 – 38.25 in for UV System 522936

Replace a cracked, damaged, or difficult-to-clean sleeve with the Pentair BioShield 523040 quartz sleeve. This replacement part is designed for the Pentair BioShield UV treatment system, model 522936.

At 38.25 in long, the sleeve houses the UV lamp inside the system while isolating it from the water. A clean sleeve in good condition allows ultraviolet light to pass properly through the quartz to maintain system performance.

Key features

• Replacement quartz sleeve
• Pentair part
• Part number: 523040
• Length: 38.25 in
• Compatible with the BioShield UV 522936 system
• Designed to accommodate the system's UV lamp
• Isolates the UV lamp from the water
• Ideal replacement for a cracked or damaged sleeve
• Transparent quartz construction

Compatibility

This quartz sleeve is designed for the following system:

• Pentair BioShield UV, model 522936
• BioShield system equipped with an 80-watt UV lamp

We recommend checking the model number listed on your BioShield system before ordering.

Function of the quartz sleeve

The quartz sleeve is installed around the UV lamp inside the BioShield system.

It notably:

• Protect the lamp from direct contact with water
• Allow ultraviolet light to pass through
• Maintain the watertight seal of the lamp compartment
• Facilitate removal and maintenance of the UV lamp
• Help ensure the proper operation of the BioShield system

Mineral deposits and dirt accumulated on the quartz can reduce the passage of UV light. The sleeve must therefore be inspected and cleaned periodically.

When should the quartz sleeve be replaced?

Replacement may be necessary when:

• The sleeve is cracked or broken
• The quartz is scratched or damaged
• The deposits can no longer be removed
• Water infiltration is observed around the lamp
• The sleeve was damaged during maintenance
• The BioShield system requires refurbishment

A cracked sleeve must not be reinstalled in the system.

Installation and handling

Quartz is a fragile material that must be handled with care.

Before installation:

1. Completely disconnect the system from the electrical power supply.
2. Stop the circulation pump.
3. Close the necessary valves.
4. Depressurize and drain the BioShield system.
5. Carefully remove the UV lamp.
6. Inspect the seals and retaining components.
7. Install the new sleeve according to Pentair instructions.
8. Check for leaks before powering the system back on.

Professional installation is recommended to prevent breaking the sleeve or damaging the UV lamp.

Maintenance tips

• Handle the sleeve with clean hands or gloves
• Avoid impacts and twisting
• Clean the quartz with a suitable product
• Do not use a wire brush
• Inspect the seals every time the system is disassembled
• Replace damaged or hardened seals
• Check for cracks before reinstalling
• Never power on the system without adequate circulation

Technical specifications

Product
Quartz sleeve for UV system

Brand
Pentair

Product line
BioShield UV

Part number
523040

Length
38.25 inches

Compatible model
Pentair BioShield UV 522936

Compatible system power
80 watts

Material
Clear quartz

Application
Ultraviolet pool treatment system

Part type
Replacement part

Package contents

• 1 38.25-inch Pentair BioShield 523040 quartz sleeve

The UV lamp, seals, retaining nuts, and other components are sold separately unless otherwise indicated.

Keep your BioShield system in good condition

The Pentair BioShield 523040 quartz sleeve is the appropriate replacement part for the 522936 UV system. Its 38.25-inch length and precise compatibility allow you to replace a damaged sleeve while keeping the other components of your installation.

Available now from Piscine Hippocampe.

Your purchase from Piscine Hippocampe

Our Delson team can advise you based on your equipment model, photos, and part references. Prepare this information to make selection easier and verify which accessories are required.
